Description

Efficiency
85 %
85 %
Output Voltage
200 – 230 V
200 – 230 V
Output Frequency
50 Hz ± 2 Hz
50 Hz ± 2 Hz
Overload
Yes
Yes
AC Output Types
Single Phase AC Output
Single Phase AC Output
Output Power
924 W
924 W
Change Over Time
20 ms
20 ms
Change Over Voltage
180–260 V (UPS Mode)
180–260 V (UPS Mode)
VA Rating
1100 VA
1100 VA
Overload Rating
110% for 10 seconds
110% for 10 seconds
Other Output Features
Short Circuit & Overheat Protection
Short Circuit & Overheat Protection
Environmental Features
Storage Temperature
-10°C to 55°C
-10°C to 55°C
Operating Temperature
0°C to 45°C
0°C to 45°C
Noise Level
<50 dB
<50 dB
Total Harmonic Distortion
<5%

Other Environmental Features
Humidity ≤95% RH (non-condensing)
Humidity ≤95% RH (non-condensing)
Input Features
Input Voltage
90 V – 290 V (ECO Mode) / 180 V – 260 V (UPS Mode)
90 V – 290 V (ECO Mode) / 180 V – 260 V (UPS Mode)
Input Frequency
50 Hz
50 Hz
Low Cut Input Voltage
90 V
90 V
Low Cut Recovery Input Voltage
100 V
100 V
High Cut Input Voltage
290 V
290 V
High Cut Recovery Input Voltage
280 V
280 V
Other Input Features
Wide input range, LVFC tech
Wide input range, LVFC tech
Battery Features
Battery Type
Lead Acid / Tubular / SMF

Recharge Time
10–12 hours (at 200 Ah)
10–12 hours (at 200 Ah)
Number of Batteries
1
1
Battery Boost Voltage
14.4 V
14.4 V
Battery Voltage
12 V
12 V
Battery Capacity
80–250 Ah supported
80–250 Ah supported
Battery Charging Current
20 Amps (Max)
20 Amps (Max)
Replacement Battery
Yes
Yes
Replacement Battery Type
Tubular/Flat Plate/SMF
Tubular/Flat Plate/SMF
Compatible Battery Types
Tall Tubular, Flat Plate, SMF
Tall Tubular, Flat Plate, SMF
Compatible Battery Make
Luminous, Exide, Amaron, Livguard
Luminous, Exide, Amaron, Livguard
Other Battery Features
Battery Gravity Builder, Smart Battery Management
Battery Gravity Builder, Smart Battery Management
In the Box
Sales Package
1 Inverter Unit, Warranty Card, User Manual

General
Brand
LUMINOUS
LUMINOUS
Model Number
Shakti Charge Neo 1450 Pro
Shakti Charge Neo 1450 Pro
Battery Included
No
No
Back Up Time
10 hrs
10 hrs
Load Options
Fans, Lights, Television, PC, Mixer, Set-Top Box, Router
Fans, Lights, Television, PC, Mixer, Set-Top Box, Router
Type
Square Wave Inverter
Square Wave Inverter
Model Name
Shakti Charge Neo 1450 Pro
Shakti Charge Neo 1450 Pro
Mode Type
Eco / UPS Mode
Eco / UPS Mode
Material
Metal with ABS Top Cover
Metal with ABS Top Cover
Fixture Type
Floor Mount

Technology Used
Square Wave, LVFC (Low Voltage Fast Charging)
Square Wave, LVFC (Low Voltage Fast Charging)
Solar Power Compatible
No
No
Switch Type
Push Button (Manual Switch between Eco/UPS)
Push Button (Manual Switch between Eco/UPS)
Electrolyte Volume
0 L
0 L
Dimensions
Width
40 cm
40 cm
Height
13 cm
13 cm
Depth
32 cm
32 cm
Weight
12 kg
12 kg
Additional Features
Certification
BIS certified
BIS certified
Corrosion Resistant
Yes
Yes
Other Features
protect from overload

Key Features
Capacity: 1100 VA / 12V – supports up to 924 Watts load, Compatible Battery: Works with single 12V batteries from 80 Ah to 250 Ah, Fast Charging Even at Low Voltage: Charges batteries even at 95V input using LVFC, Intelligent 32-bit DSP Processor: Ensures efficient power delivery and protection, Backup Time: 6 to 10 hours (depending on battery capacity and usage, Output Type: Square Wave – ideal for fans, lights, TV, PC, mixer, router, and more, Modes: UPS Mode: 180V–260V (for computers & sensitive appliances) Eco Mode: 90V–290V (for energy saving), Overload, Short Circuit & Deep Discharge Protection, Supports High Power Appliances During Cut, Build: Rugged design with digital display and ergonomic indicators
